CNC Oval
Available colors

CNC Oval

Minimalist recessed step light. Also suitable for outdoor use. Aluminium body (made of AISI 316L stainless steel for the sandblasted stainless steel version). Wide choice of colour temperatures and optics. Clear glass diffuser. The product has an IP 67 rating and is fitted with an integrated Aquastop system that protects it from water ingress and humidity. Pre-wired luminaire with a multi-year warranty on the LED circuit, supplied with H05RN-F 2x0.75 power cable. 24Vdc power supply not included. Honeycomb version available (not available with D lens). LED 4000K (N) or 3000K (3), 2700K (2) or 2200K (1). No photobiological risk under normal conditions of use; RG1 risk group exempt (EN62471).
IP 67
Outdoor e waterproof
24 V
24 V
Aquastop
Aquastop
Dimmable
Dimmable
Pre-wired
Pre-wired
Minimum Environmental Criteria
Minimum Environmental Criteria
5 years warranty on LED circuit
5 years warranty on LED circuit
Diffuser
Transparent glass
CNC Oval
  • IP 67
  • IK 06 1J xx3
  • Temp. max on diffuser 65°C
  • CE
Optic D not available for Honeycomb version.
Light beam
simmetrico
LED
W LM REAL LM COL. CODE Download
4 294 270
CL.III 24V 24V
Sandblasted Grey
LT158400
Grey anthracite RAL 7021
LT15840E
Corten
LT15840K
4 294 130
CL.III 24V 24V HONEYCOMB
Sandblasted Grey
LT15840H0
Grey anthracite RAL 7021
LT15840HE
Corten
LT15840HK
Complete the CODE
OPTIC
S
20°
M
30°
L
45°
D
Diff.
LED COLOUR
N
4000K
3
3000K
2
2700K
1
2200K
OPTIONAL CABLES
HO5RN-F 2x0.75 cable 4 | 5m 5 | 10m 6 | 15m 7 | 20m

Lighting simulations

cnc_oval_optic_D
cnc_oval_optic_D
cnc_oval_optic_L
cnc_oval_optic_L
cnc_oval_optic_M
cnc_oval_optic_M
cnc_oval_optic_S
cnc_oval_optic_S
cnc_oval_honeycomb_optic_L
cnc_oval_honeycomb_optic_L
cnc_oval_honeycomb_optic_M
cnc_oval_honeycomb_optic_M
cnc_oval_honeycomb_optic_S
cnc_oval_honeycomb_optic_S
