Stile next 506E
Design: Lombardo design department

Stile next 506E

Suitable for indoor and outdoor use.
Body made of EN-AB44100 die-cast aluminium primary alloy; highly resistant to oxidization thanks to the zirconium-based passivation treatment and UV stabilized polyester resin coating.
Heat tempered and serigraphed glass diffuser.
Silicone gaskets.
A4 or AISI 316 L stainless steel nuts and bolts.
Patented model.
LED 4000K (N), 3000K (3) or 2700K (2). LED. Integral ballast 220-240V. No risk of photobiological damage, RG0 group (EN62471).
Diffuser
Serigraphed glass
Available configurations
Wall Wall recess Ceiling recess Ceiling
Download
Ask for information
Stile next 506E
  • IP 66
  • IK 06 1J xx3
  • CE
Double cable entry at the back.
LED
W LM REAL LM COL. DIFF. Opal.
CODE
LED COLOUR
A++ 6 720 283 CL.I Led versions with integral ballast
N
4000K
3
3000K, lm -5%
