High power
lighting division
Kai 1
Available colors

Kai 1

New
Suitable for external pole installation, body in die-cast aluminum. IP 66. Diffuser in transparent glass. On-off version: cable 0.7m H05RN-F. DALI version: cable 0.7m H07RN-F. Mandatory installation on Ø60 metal poles. Not suitable for Still poles. A4 stainless steel hardware. Prepared for D4i and midnight function. Wide choice of color temperatures and finishes. Supplied with "Bordo Mare" treatment ideal for installations in areas at greater risk of corrosion. The product body is made of die-cast aluminum; high resistance to oxidation thanks to zirconium-based passivation treatment and coating with UV-stabilized polyester resins. Pre-wired device with multi-year warranty on LED circuit. Proprietary fixing system with internal pole integration for elimination of visible external elements. LED 5700K (5), 4000K (N) or 3000K (3). No photobiological risk under normal conditions of use; RG1 exempt risk group (EN62471).
IP 66
Outdoor e waterproof
Direct power supply
Direct power supply
Dimmable
Dimmable
Pre-wired
Pre-wired
Midnight function
Midnight function
D4i
D4i
Sea Treatment
Sea Treatment
5 years warranty on LED circuit
5 years warranty on LED circuit
Available from
Orderable from September 2025
Diffuser
Transparent glass
Installable on post 60
Kai 1
  • IP 66
  • IK 08 5J xx7
  • CE
Cable on-off: 0,7m H05RN-F. Cable DALI version: 0,7m H07RN-F. Recommended for installation on Ø 60 metal poles. Not suitable for Still poles.
LED
W LM REAL LM COL. CODE Download
25 4500 Max. 3599
CL.II LED version with integrated ballast 220-240 V
Grey High Tech RAL 9006
LL16411G
Grey anthracite RAL 7021
LL16411E
Corten
LL16411K
Black RAL 9005
LL16411B
25 4500 Max. 3599
CL.II LED version with integrated ballast 220-240 V DALI2
Grey High Tech RAL 9006
LM16411G
Grey anthracite RAL 7021
LM16411E
Corten
LM16411K
Black RAL 9005
LM16411B
40 6300 Max. 4997
CL.II LED version with integrated ballast 220-240 V
Grey High Tech RAL 9006
LL16412G
Grey anthracite RAL 7021
LL16412E
Corten
LL16412K
Black RAL 9005
LL16412B
40 6300 Max. 4997
CL.II LED version with integrated ballast 220-240 V DALI2
Grey High Tech RAL 9006
LM16412G
Grey anthracite RAL 7021
LM16412E
Corten
LM16412K
Black RAL 9005
LM16412B
Complete the CODE
OPTIC
A1
70° X 150°
A2
65° X 130°
A3
50° X 150°
A4
60° X 150°
A5
30° X 80°
LED COLOUR
5
5700K
N
4000K
3
3000K

Lighting simulations

kai1_25W_A1
kai1_25W_A1
kai1_25W_A2
kai1_25W_A2
kai1_25W_A3
kai1_25W_A3
kai1_25W_A4
kai1_25W_A4
kai1_25W_A5
kai1_25W_A5
kai1_40W_A1
kai1_40W_A1
kai1_40W_A2
kai1_40W_A2
kai1_40W_A3
kai1_40W_A3
kai1_40W_A4
kai1_40W_A4
kai1_40W_A5
kai1_40W_A5
